Serie 7 V-Shift Tier3

SERIE 7 TIER3, TRACTOR RANGE, A GREAT TRADITION OF EFFICIENCY.

The new Serie 7 Tier 3 tractors are designed to satisfy the most exacting needs of modern farms and agricultural contractors. Inspired by the automotive design, the new tractor range has been restyled with a more dynamic look and high-quality fit and finish and offers a spacious cab with ergonomically-arranged, intuitive controls for maximum comfort and ease of operation. The cab roof has been fully redesigned and the 12 work lights have been repositioned to provide full all-round visibility for night-time operation. The hood has also been reshaped to enhance visibility to the front

Engine Cyl / L: 6 / 6.7

Power HP: 230

Transmission: V-Shift

Request Information

Strong points of the SERIE 7 V-Shift Tier3.

Cab
Engine
Transmission
Hydraulics

Request a Quote

Download the Brochure

LOUNGE CAB: SUPERIOR COMFORT FOR GREATER PRODUCTIVITY.

The Landini Serie 7 Tier 3 features the new Lounge Cab, an innovative four-post cab with rear-hinged doors that provides exceptional all-round visibility. The new cab offers a highly efficient sound insulation system which maintains an in-cab noise level of only 70 dB for maximum comfort of operation. An electrohydraulic semi-active suspension system is optionally available to further enhance ride comfort. Wide and well-spaced access steps allow the operator to easily get in and out of the cab, while the buddy seat neatly folds away making for easier and safer access. The cab interior features an automotive-style fit and finish with easy-clean soft-touch materials. The instrument panel and the steering wheel can be electrically adjusted in tilt and depth to suit the driver’s needs.

The Alcantara upholstered swivel seat with dynamic air suspension system and fully automatic height adjustment features backrest heating and ventilation for ultimate driving comfort. The multifunction righthand armrest accommodates the main tractor controls arranged in a simple and logical manner. In addition, an ergonomically-designed multifunction controller provides easy and intuitive control of key tractor functions. Integrated into the armrest is a 12-inch touch screen monitor with sim[1]ple tablet-like graphics that allows the operator to quickly manage and adjust the tractor operating parameters. The Lounge Cab’s standard equipment includes a refrigerated in-cab storage compartment, a bottle holder, 12V sockets for charging mobile devices, an internal mirror and an opening transparent roof hatch providing extra visibility for loader operations. Integrated into the cab roof, a highly-efficient automatic climate control system maintains the desired cab temperature whatever the outdoor weather conditions.

NEW FPT N67 ENGINES: PLENTY OF PULLING POWER IN THE FIELD.

The Serie 7 tractor range meeting the Tier 3 emission standard is powered by the new FPT N67 six-cylinder turbo engines with multivalve technology and electronic common rail injection system. The engines are located within a rugged chassis which helps reduce noise and vibra - tion levels within the cab. An electronically-controlled viscotronic fan, standard on the entire range, improves the engine cooling efficiency, while reducing fuel consumption and noise levels. The FPT N67 engines are equipped with the Dual Power system which electronically adjusts the engine power to respond to varying load conditions, maintaining speed and productivity. During transport applications or PTO operations, the Dual Power automatically delivers an additional 10 hp, boosting engine power up to 190, 210 and 230 hp, respectively. The new FPT N67 fitted on the Serie 7 Tier 3 tractors are state-of-the-art engines designed to offer farmers simplicity and functionality without compromising on performance, reliability and durability.

V-SHIFT AND ROBO-SIX TRANSMISSIONS.

High performance, fuel efficiency, smooth driving and safety are the strong points of the Robo-Six transmission. The key features of this transmission include five speed ranges, a six-speed on-the-go powershift, a robotized range shifting and an electrohydraulic steering column power shuttle. The Robo-Six transmission offers 30 forward and 15 reverse speeds. In addition, a creep speed option provides 54 speeds forward and 27 speeds in reverse. Where legally permitted, the Serie 7 Tier 3 can reach a top speed of 50 km/h at reduced engine rpm. In addition, the Robo-Six transmission is equipped with an oil cut-off function which ensures a more efficient management of the braking system, resulting in better performance on the road and improved fuel economy.

The V-Shift transmission with its four-stage technology sets a new benchmark in continuously variable transmissions. Using a four-stage instead of the usual two-stage CVT transmission offers real benefits to farmers and agricultural contractors looking for maximum productivity in any application.

This transmission offers four speed ranges to suit different operating requirements:

Range 1 - Creeper 0 – 3 km/h
Range 2 - Field 1 0 – 12 km/h
Range 3 - Field 2 0 – 21 km/h
Range 4 - Transport 0 – 40 or 50 km/h

The V-Shift transmission features four operating modes:

Auto Mode - The electronic unit controls the engine rpm and transmission ratio, based on the parameters set on the potentiometer, in order to achieve the required speed.
Manual Mode - The operator sets the engine speed with the hand throttle. The electronic unit controls the transmission ratio in order to achieve the required speed.
PTO Mode - The operator sets the engine speed with the hand throttle. The electronic unit controls the transmission ratio in order to achieve the required speed. In this mode, priority is given to the PTO speed.
Cruise Mode - The operator selects the tractor travel speed, which remains constant
